The drag plate of the unloading rack is made of 304 stainless steels, with a smooth surface and friction resistance. The inclination angle is 25° when unloading, so the pipe will automatically fall into the finished product collection box after cutting.
A set of variable-diameter wheels can meet the lifting requirements of all pipes. The height adjustment of the unloading rack pallet is driven by a motor, so the supporting height of the pallet can be adjusted by one button to meet the needs of different pipe diameters.
The follow-up support module adopts up-down and left-right directions to support the pipe at the same time, so that the slender pipe is clamped more firmly, minimizes the shaking during the cutting process, and solves the problem of processing accuracy.
The chuck has a wide clamping range and a large bearing capacity. Equipped with 240 pneumatic square chuck, the maximum bearing capacity is 300KG. The chuck can clamp both round and square tubes to a range of 20-240mm.
The pointed nozzle cutting head dedicated for pipe cutting machine can meet the cutting requirements of I-beam and channel steel materials and avoid nozzle interference during the cutting process.
Equipped with a high-performance CNC laser cutting system, which has the characteristics of fast interpolation calculation speed and convenient operation.
